KingTech K-260G4 Turbine Engine

KingTech
|
K260G4
$3,650.00 $0.00( / )
Special Order: Processing time is about 3 - 10 business days KingTech G4 utilizes SBus data transmission. Engine/ECU integration, all operating parameters including total run time are all recorded into the engine. The smaller and lighter external Data Relay Module (DRM) is responsible for all data, signal and power transmission. A...
Add to Wishlist

Special Order: Processing time is about 3 - 10 business days

  • KingTech G4 utilizes SBus data transmission.
  • Engine/ECU integration, all operating parameters including total run time are all recorded into the engine.
  • The smaller and lighter external Data Relay Module (DRM) is responsible for all data, signal and power transmission.
  • A micro USB connector is present for a future connectivity of wireless mobile apps.
  • The G4 features a brushless starter motor for reliability and durability, built-in FOD screen is also integrated.
  • After a run cycle and receiver switched off, GSU will remain on only until cool down completes.

K-260G4 SPECIFICATIONS

Diameter: 120 mm
Length: 299 mm
Weight: 2.2 kg
RPM Range: up to 33,000-112,000RPM
Max Thrust: 26 kg ±0.5
EGT: 700°C max
Fuel consumption: 760 g / min (26.80 oz / min)
Fuel: Diesel, Jet A1, Kerosene
Lubrication: 5%
Maintenance cycle: 25 hr US$350>



G4 MODEL COMPONENTS LIST

• Engine
• Data Relay Module (DRM)
• Ground Support Unit (GSU)
• Wire Harness and Tubing Set
• Fuel Pump, Filter and Shout-off Valve
• Fuel Inlet Attchments
